Drei-Phasen-Vier-Draht-Wandmontage-statische VAR-Generator

The Three-Phase Four-Wire Wall-Mounted Static Var Generator (SVG) provides dynamic reactive power compensation and load balancing for three-phase 380V, 500V, and 690V four-wire electrical systems. Utilising advanced DSP+CPLD digital control and a three-level topology, this SVG delivers precise and rapid compensation with a response time under 10ms. Its modular design enables scalable capacity through parallel connection, while the wall-mounted configuration simplifies installation and minimises space requirements. This SVG effectively compensates for both inductive and capacitive reactive power, addresses three-phase imbalances, and enhances overall power quality. Available capacities range from 15kvar to 120kvar, offering flexible solutions for diverse applications.

Model description:

Features:

● Use DSP+CPLD all digital control core, three-level topology technology, advanced reactive power detection algorithm and PWM control strategy to achieve dynamic and accurate compensation of reactive power.
● Adopt modular design, which facilitates parallel connection of multiple modules, takes small space and is easy to maintain.
● The structural design of independent air ducts and independent warehouses ensures the stable operation of the equipment.
● Carry out full-range dynamic compensation for inductive reactive power and capacitive reactive power, and solve the three-phase unbalance problem at the same time.
● The dynamic response speed to the load is at the millisecond level, which can achieve dynamic and accurate compensation for the reactive power of impact loads.

Applications:

Three-Phase Four-Wire Wall-Mounted Static Var Generators are ideal for power quality improvement in various four-wire applications:

● Industrial Power Distribution: Stabilising voltage and improving power factor in four-wire industrial environments.
● Commercial Buildings with Unbalanced Loads: Correcting three-phase imbalances and reducing neutral current in four-wire systems.
● Data Centres and IT Facilities: Ensuring reliable power quality for sensitive electronic equipment in four-wire power distribution networks.
● Renewable Energy Systems: Supporting grid stability and power quality in four-wire systems with integrated renewable energy sources.

Three-Phase Four-Wire Wall-Mounted Static Var Generators offer a robust and efficient solution for optimising power quality and stability in three-phase four-wire electrical systems.

Technical Parameters:

Model& Specification:
